Essential Fasteners for 3D-Printed Functional Parts

Build brackets, enclosures and mechanical assemblies that can be opened, repaired and reused. Compare brass inserts, M3/M4 machine screws, hex nuts, Nyloc nuts and washers—and learn when each joint makes sense.

Practical selection guideTables & original diagramsChecked 22 October 2026

Illustrative hardware assembly. Geometry, screw length and insert size must be matched to your actual printed part.

Quick answer: For a 3D-printed part that you must open repeatedly, use a compatible brass threaded insert with a matching machine screw. If both sides of the joint are accessible, a through-bolt with washer and nut is often simpler. A captured hex nut works when you can model a nut pocket into the print. Joint geometry and printed material matter as much as screw size.

Three reliable ways to join 3D-printed parts

There is no single “best 3D printing screw.” Pick the fastening strategy first, then choose the matching thread, length and installation method. Metal-on-metal threads are useful when an assembly needs repeated service, but the surrounding plastic must still resist the load.

Three illustrated methods: machine screw into brass insert, through bolt with washer and nut, and captive hex nut in a 3D-printed pocket.
Choose by access, service frequency and the load path through the printed part. These are schematic examples, not guaranteed strength ratings.
Joint method Best use Advantages Important check
Brass insert + machine screw Repeatedly opened housings, equipment covers Reusable metal threads, hidden nut Thermoplastic compatibility, boss wall and pilot size
Through-bolt + nut + washer Brackets, fixtures and accessible assemblies Clamps two parts without relying on printed threads Access to back, washer bearing area and bolt length
Captured hex nut Blind access, replaceable hardware, no heating Metal thread in a designed pocket Nut pocket fit, retention and assembly clearance
Screw designed for plastic Selected low-load or limited-cycle joints Fewer separate parts Correct screw geometry and validated pilot hole; wear with reuse

Fastener selection table: what each item does

Hardware Use it for Typical pair Avoid this mistake
M3 or M4 socket-head machine screw Joining printed covers, panels and brackets Matching brass insert or nut Driving a machine screw into an undersized plain plastic hole as if it were a plastic-forming screw
Knurled brass threaded insert Repeat-service threads in compatible printed thermoplastics Same-size machine screw Using the M3 thread diameter as the printed pilot-hole diameter
Hex nut Through-bolts or printed nut pockets Matching M3/M4 bolt Leaving inadequate clearance for a spanner or nut pocket
Nyloc nut Joints needing prevailing-torque resistance to loosening Suitable through-bolt Assuming its nylon ring is suitable for every high-temperature application
Plain washer Spreading head or nut bearing contact Bolt or screw under the head/nut Thinking a small washer makes a thin printed wall load-proof
Assorted M3/M4 kit Prototyping multiple sizes and lengths Test-fit before committing to one SKU Mixing M3 and M4 parts or mismatching thread pitch

Brass threaded inserts: when the part will be opened repeatedly

A heat-set insert has a knurled metal body and an internal machine thread. Installed into a properly designed thermoplastic boss, the surrounding plastic can reflow around its outer features and hold a reusable metal thread. PLA, PETG and ABS parts may be suitable depending on the insert design and material-specific process; resin prints require a different validated installation approach.

OnlyScrews carries M3 × 4 mm and M3 × 6 mm slant-knurled brass inserts, plus an M4 × 4 mm option. These dimensions describe the nominal internal thread and insert length—not a universal printed hole diameter.

Three-panel technical manual: design printed boss, heat and seat brass threaded insert squarely, let cool and test with machine screw.
Use a controlled heating tool and an appropriately matched insert-installation tip. The diagram shows the sequence only; do not copy a temperature or hole dimension without the exact insert specification.

Before installing an insert

01 · Select the actual insertRead its external diameter, length, thread pitch and intended installation method. Do not infer the pilot diameter from “M3” or “M4.”
02 · Design and test the bossLeave sufficient wall material and hole depth, and print a small test piece to confirm fit in your actual filament, printer and orientation.
03 · Install squarely and coolFor approved thermoplastics, use a controlled heat-set process. Let the part cool fully before driving or loading the screw.

For a deeper insert-specific selection guide, see How to Choose Brass Threaded Inserts for 3D Printing. This article focuses on the complete fastened assembly.

Choosing M3 and M4 machine screws—and the correct length

Machine screws require a matching metal thread, such as an insert or nut. A screw marked M3 normally mates with an M3 internal thread (common coarse pitch 0.5 mm); an M4 machine screw commonly uses M4 × 0.7. Always confirm pitch and engagement instead of relying on diameter alone.

For small electronics enclosures and printed brackets, socket-head screws are practical because they suit Allen keys and are available in short lengths. The M3 × 8 mm, M3 × 12 mm and M4 × 8 mm SS304 socket-head screws provide examples, not universal recommendations.

Technical cross-section comparing a correctly engaged screw and a screw that bottoms out inside a brass threaded insert in a printed part.
Select length from the stack-up, desired thread engagement and remaining depth. Example is schematic; no fixed screw length is specified.
Selection check What to measure Why it matters
Nominal thread & pitch M3 × 0.5 or M4 × 0.7, unless specified otherwise Prevents incorrect thread engagement
Fastener length Stack thickness + washer + required engagement Too short gives poor engagement; too long can bottom out
Head and drive Access for Allen key; head-seat geometry Avoids driver interference or damaged plastic
Printed material Boss wall, print layers, service temperature Hardware cannot compensate for inadequate plastic geometry

Use a screw-length measurement guide if the part uses a countersunk rather than a socket head. Screw length is generally measured from under a non-countersunk head, while a countersunk screw is measured differently.

Hex nuts, Nyloc nuts and washers: what changes in a 3D-printed joint?

A hex nut provides reusable metal threads in a through-bolt joint or a deliberately designed hexagonal captive pocket. A Nyloc nut adds prevailing torque that can help resist loosening, but the nylon element has service-temperature limitations. Neither replaces good joint alignment or appropriate preload.

A plain washer spreads contact beneath a screw head or nut, helping reduce concentrated pressure against the print. In a joint carrying sustained clamp load, thermoplastic creep and compression can still reduce preload; high-load assemblies may need more substantial bearing features or a correctly designed compression limiter.

Common part Recommended hardware approach What to verify
Sensor or electronics case M3 screw + compatible threaded insert Repeated opening, pilot design, boss wall thickness
Robot arm bracket or fixture Through-bolt + washer + nut where accessible Clamp area, load, layer orientation and clearance
Camera/RC mounting accessory Suitable socket-head screw + captive nut or insert Mechanical compatibility, service load, vibration
Removable hinged access panel Machine screw + inserts; washer as needed Hinge geometry, repeated cycles, engagement
Prototype with unknown final length M3/M4 assortment for test-fitting Do not force an incorrect screw size into a print

Fastener selection flowchart

This decision flow starts with access to the back of the joint, then considers printed material and how often you expect to remove the fastener. The final decision still depends on structural loading, temperature and component tolerances.

Decision flow for 3D-printed part fasteners: through-bolt and nut, brass heat-set insert and machine screw, or captive nut/resin-compatible system.
A simplified decision aid. It is not a substitute for mechanical design verification or load testing.

Five checks before committing a functional print

1 · Decide where the load goesVisualize pulling, shear and clamp forces. Add sufficient plastic around holes, bosses and pockets rather than simply increasing infill.
2 · Keep hardware measurements separateM3 means nominal thread size; it does not tell you the outside diameter of a brass insert or the pilot required in your print.
3 · Make test couponsTest one boss and one nut pocket before printing an entire enclosure. Printer compensation and filament shrinkage change the fit.
4 · Plan for service and corrosionCheck if the enclosure is opened repeatedly, cleaned, outdoors or exposed to heat. Match metal, coating and retaining method to that environment.
5 · Tighten carefullyUse controlled torque and a suitable driver; printed plastic can split, creep or crush even when the screw and nut are strong.

Verified OnlyScrews hardware for 3D printing

These ten OnlyScrews products were checked in the live Shopify catalogue on 22 October 2026. They were active with positive reported inventory at the time of checking; availability, pack quantity and pricing should always be checked on the product page.

Frequently asked questions

Are M3 and M4 screws the most useful sizes for 3D printing?

They are common for hobby and small functional assemblies, but the right size depends on the product geometry, load, available plastic and the joining hardware. Larger or smaller threads can be more appropriate.

Can I use an M3 machine screw directly in a printed PLA hole?

Do not assume a standard machine screw is designed to form its own threads in an undersized printed hole. For frequent assembly, choose a compatible heat-set insert or captive nut. For direct-to-plastic fastening, use a rated plastic-thread-forming screw and validated hole design.

Is an M3 brass insert's outer diameter 3 mm?

No. M3 identifies the nominal internal thread. Insert outer diameters vary by design. Check the actual part drawing or product dimensions before designing the printed pilot hole.

Can I heat-set brass inserts into any SLA resin print?

Do not apply thermoplastic heat-setting instructions to a thermoset resin part. Use a joining method compatible with the specific resin and hardware, such as an appropriately engineered captive nut or resin-rated insert/bonding system.

Should I use a hex nut or a Nyloc nut?

Use a standard hex nut for an ordinary accessible connection if no prevailing-torque locking is needed. Consider a Nyloc nut for suitable applications where resistance to loosening matters, after checking temperature, reuse and fastening requirements.

Will a washer stop 3D-printed plastic from cracking?

A washer distributes local contact pressure but cannot fix thin walls, poor layer orientation, excessive torque, incorrect geometry or an overstressed joint. Verify the actual load path and test the printed component.

The bottom line

For functional 3D prints, begin with the joint design: access, load, material and service frequency. Then select a matching machine screw, brass insert or nut—and add washers or locking features only where they solve a defined problem. When in doubt, prototype a joint, check the engagement, and test before relying on it in service.

Educational hardware-selection guidance. Do not infer safety-critical load capacity or mandatory installation settings from these schematics.
